Overview
The Rosemount 8800 Wafer Vortex Flow Meter is a lightweight and cost-effective solution for flow measurement in liquid, gas, and steam applications. Its gasket-free, non-clog meter body helps reduce potential leak points and supports reliable long-term operation in industrial utility and process environments.
Key Features
- Wafer-type vortex flow meter
- Suitable for liquid, gas, and steam measurement
- 4-20 mA with HART 5 or 7
- Optional scalable pulse output
- Gasket-free, non-clog meter body
- Isolated sensor design
- Liquid accuracy up to ±0.65% of volumetric rate
- Gas and steam accuracy up to ±1% of volumetric rate
- Turndown up to 38:1
- Lightweight design for easier installation in utility applications
Applications
This series is suitable for utility lines and general industrial process measurement where stable performance, reduced maintenance, and compact installation are important. It can be used for liquid, gas, and steam flow monitoring in a wide range of industrial systems.
Specifications Overview
- Product Type: Wafer Vortex Flow Meter
- Brand: Rosemount
- Series: 8800
- Measured Media: Liquid, Gas, Steam
- Output: 4-20 mA with HART 5 or 7
- Optional Output: 4-20 mA with HART 5 or 7 and scalable pulse output
- Liquid Accuracy: ±0.65% of volumetric rate
- Gas / Steam Accuracy: ±1% of volumetric rate
- Turndown: 38:1
- Line Size: 1/2″ – 8″ (15 – 200 mm)
